Two Head Ampoule Filling Sealing Machine

Two Head Ampoule Filling Sealing Machine

225000 INR

Product Details:

  • Product Type Ampoule filling sealing machine
  • Computerized No
  • Automatic Grade Automatic
  • Control System Frequency Speed Control
  • Drive Type Electric
  • Voltage 230 Volt (v)
  • Weight (kg) 200 Kilograms (kg)
  • Supply Ability : 1-2 Piece Machine Per Month
  • Click to view more
X

Price And Quantity

  • 1 Piece
  • 225000 INR

Product Specifications

  • No
  • Ampoule filling sealing machine
  • Electric
  • 1000 L * 1070 W * 965 H Millimeter (mm)
  • Frequency Speed Control
  • 12 Month
  • Automatic
  • Stable Performance, High Efficiency, Lower Energy Consumption, Low Noise, ECO Friendly, High Performance, Simple Control
  • 230 Volt (v)
  • 200 Kilograms (kg)

Trade Information

  • 1-2 Piece Machine Per Month
  • 15-20 Days
  • All India

Product Description

Two Head Ampoule Filling Sealing Machine is one of the most critical equipment which has significant roles to play in processing of pharmaceutical products particularly liquids. It is built on the principle based on slant traveling of ampoules when it is filled and sealed. This machine is ideal to wash ampoules having 1 to 10 ml quantity. This machine is robust in terms of construction and other hassle-free operations and widely used in pharmaceutical biotech veterinary, agriculture chemical cosmetics industries etc. Our offered Two Head Ampoule Filling Sealing Machine is designed to wash ampoule by making minimum contact of ampoule with machine parts.


TECHNICAL SPECIFICATION :

Equipment

:

 Two Head Ampoule Filling Sealing Machine







Model

:

AFS-50







Optimum output



20 to 40 Ampoule/min.





20 Amp/Min for 20ml

25 Amp/Min for 10ml

Overall dimensions

:

1000  mm L * 1070  mm W * 965mm H







Electric Power Supply

:

230V. 1 Phase,1H.P







Ampoule Size

:

Min. 9.5mm Dia  to  Maxi. 22mm Dia (1ml to 25l)







Construction details

:

The equipment consist of Hopper with loading Tray at infeed, Filling & Sealing station





       Loading tray  : SS 304

       Frame            : SS 304

       Body Plates   : Claded with SS 304 sheet

All Contact Parts :  S.S 316







Change Parts

:

Star Wheel & Needle







Ampoule  Collection

:

Collect in Trays







New Feature



A.C Drive

Digital Counter

New Clutch design with clutch wire system

Pre Heating system

Pre & post nitrogen gassing system

Weight



Net Weight: 250 kg Approx
